Datalogic MAGELLAN 8300 Product Reference Guide

6-272 Magellan
®
8300/8400
DataBar Expanded Length 2
Length 2 is the maximum label length if in variable length mode, or the
second fixed length if in fixed length mode (see
DataBar Expanded
Length Control). Length includes the barcode’s check and data characters.
To set this feature:
1. Scan the SWITCH bar code.
2. Scan the bar code,
SET DataBar Expanded LENGTH 2 below.
You’ll need to cover any unused bar codes on this and the facing
page to ensure that the scanner reads only the bar code you intend
to scan.
3. Scan the appropriate digits from the keypad in
Appendix C that rep-
resent the desired label length. A setting of 000 will ignore this
length (only one fixed length), otherwise, the selectable range for
this option is 001 to 074. Pad all single and double digit numbers
with leading zeroes to yield a three-digit entry (001-074).
4. Complete the programming sequence by scanning the SWITCH
bar code.
SET DataBar Expanded LENGTH 2

Datalogic MAGELLAN 8300 Specifications

General

Read rate (max)	3900 reads/s
Decoding standards	1D, GS1 DataBar
Standard interfaces	Keyboard Wedge, RS-232
USB 2.0 ports quantity	1
Input voltage	100 - 250 V
Product color	Metallic
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	130 mm
