MSI/Plessey Enable
Product Reference Guide 6-359
MSI/Plessey Length 1
Length 1 is the minimum label length if in variable length mode, or the
first fixed length if in fixed length mode (see
MSI/Plessey Length Con-
trol). Length includes the barcode’s check and data characters.
To set this feature:
1. Scan the SWITCH bar code.
2. Scan the bar code,
SET MSI/PLESSEY LENGTH 1 below. You’ll
need to cover any unused bar codes on this and the facing page to
ensure that the scanner reads only the bar code you intend to scan.
3. Scan the appropriate digits from the keypad in
Appendix C that rep-
resent the desired label length. The selectable range for this option is
004 to 016. Pad all single and double digit numbers with leading
zeroes to yield a three-digit entry (004-016).
4. Complete the programming sequence by scanning the SWITCH
bar code.
SET MSI/PLESSEY LENGTH 1

Datalogic MAGELLAN 8300 Specifications

General

Read rate (max)	3900 reads/s
Decoding standards	1D, GS1 DataBar
Standard interfaces	Keyboard Wedge, RS-232
USB 2.0 ports quantity	1
Input voltage	100 - 250 V
Product color	Metallic
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	130 mm
