Datalogic MAGELLAN 8300 Product Reference Guide

A-6 Magellan
®
8300/8400
Calibration Switch
This switch initiates the scale’s calibration routine. A certified weight set is
needed to perform the scale calibration steps detailed in
Chapter 5, Cali-
bration. This switch is not included in scanners without scale modules.
Calibration Switch Seal
This seal allows you to secure the Calibration Switch access cover and
restrict access to the Calibration Switch. If the calibration seal is broken or
missing, you may be prohibited from operating the scale without recertifi-
cation. Check local and state requirements for specific restrictions.
Calibration Switch
A cover restricts access to the Calibration Switch to help guard against
unauthorized tampering when sealed. The Calibration Switch is located
just beneath the Spider in the location indicated in
Figure A-1.
Figure A-1. Calibration Switch
LEGAL NOTE
There are regulations that must be followed in order to ensure
compliance when operating a weighing device such as the scan-
ner/scale. Failure to observe and comply with these regulations
could result in legal action.
LEGAL NOTE
Spider
Calibration
Switch

Datalogic MAGELLAN 8300 Specifications

General

Read rate (max)	3900 reads/s
Decoding standards	1D, GS1 DataBar
Standard interfaces	Keyboard Wedge, RS-232
USB 2.0 ports quantity	1
Input voltage	100 - 250 V
Product color	Metallic
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	130 mm
