Installation Overview
Product Reference Guide 2-21
Checkstand Mounting
There are a number of things to take into account when installing the unit
into a checkstand. Key factors are ergonomic/worker safety, loading capac-
ity and stability. Consider the scanner or scanner/scale’s weight when cal-
culating the robustness of construction needed to support it as well as
maximum capacity of weighed and scanned items.
Checkstand Vibration
Proper function of the scanner/scale is dependent upon an installation
which minimizes excess vibration from conveyor belts, fans, and other
such equipment. See Chapter 4, Scale Error Reporting, if vibration is
suspected of causing operational problems.
Installation Overview
The preceding Site Preparation Overview dealt with installed location
and counter preparations to accommodate the scanner or scanner/scale.
Having completed those steps, physical installation of the scanner or scan-
ner/scale can begin. The following instructions apply to all models.
This chapter describes:
1. Unpacking the unit.
2. Verifying operation before connecting to a POS system.
3. Routing and connecting cables.
4. Validating that your scanner communication parameters match the
POS terminal’s system requirements.
5. Confirming connection to the (optional) EAS system.
NOTE
If you choose to rout a countertop with a thickness of 0.75” (1.9 cm) plywood,
you’ll need to add a backing strip that supports the area routed out for the
support flanges (see Figure 2-7). This support strip should minimally be
made of 0.75” (1.9 cm) thick plywood and be approximately 4.0” (10.2 cm)
wide and 14.0” (35.6 cm) long. This strip should be glued as well as screwed
to the underside of the countertop.
