Datalogic MAGELLAN 8300 Product Reference Guide

3-4 Magellan
®
8300/8400
Proper Weighing Technique
1. The L-shaped All-Weighs™ platter allows you to place items any-
where on its surface, including leaning against its vertical section, to
be weighed accurately. The “Produce Rail” or (when raised) the
“Produce Bar” also provide a convenient way to ensure items do not
rest on the counter or other non-weighing surfaces. (Reference
Figure 3-2.)
Figure 3-2. All-Weighs™ Platter & Item Placement
2. Once weighed items are in place, enter PLU (price Look-Up) data as
described in your POS system instructions. Item weight is displayed
on the Remote Display and/or the host display.
3. Remove the item from the weigh platter.
NOTE
It is important that items rest entirely on the platter for their full weight to be
accurately recorded.
All-Weighs
®
Platter
Produce
Bar Option
Produce
Rail Option

Datalogic MAGELLAN 8300 Specifications

General

Read rate (max)	3900 reads/s
Decoding standards	1D, GS1 DataBar
Standard interfaces	Keyboard Wedge, RS-232
USB 2.0 ports quantity	1
Input voltage	100 - 250 V
Product color	Metallic
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	130 mm
