Datalogic MAGELLAN 8300 Product Reference Guide

Keyboard Wedge/USB Keyboard Features
Product Reference Guide 6-165
Keyboard Interface — Control Characters
Specifies how the scanner transmits ASCII control characters to the host.
Choices are:
• Disable Control Characters
• Enable transmission of control characters to host
• Send characters between 00H and 1FH according to a special func-
tion-key mapping table. (This is used to send keys that are not in
the normal ASCII set; a unique set is provided for each available
scancode set. Reference
Appendix E, Keyboard Function Key Map-
pings
.)
To set this feature:
1. Scan the SWITCH bar code.
2. Scan your choice from the Control Characters feature bar codes
below. You’ll need to cover any unused bar codes on this and the fac-
ing page to ensure that the scanner reads only the bar code you
intend to scan.
3. Complete the programming sequence by scanning the SWITCH
bar code.
CONTROL CHARACTERS = DISABLE
NOTE
This feature does not apply to the USB Keyboard interface.

Datalogic MAGELLAN 8300 Specifications

General

Read rate (max)	3900 reads/s
Decoding standards	1D, GS1 DataBar
Standard interfaces	Keyboard Wedge, RS-232
USB 2.0 ports quantity	1
Input voltage	100 - 250 V
Product color	Metallic
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	130 mm
