Datalogic MAGELLAN 8300 Product Reference Guide

Product Reference Guide G-11
• Prefix must be ASCII characters ']E0'- total length including prefix
must be 16.
• Example: ']E01101234567891'.
EAN-8
• Check digit must be included in label data and is assumed to be cor-
rect.
• Prefix must be ASCII characters ']E4' - total length including prefix
must be 11.
• Example: ']E400210126'.
2-Digit Supplemental
• Supplemental data is appended to any EAN base label.
• Prefix must be ASCII characters ']E1'.
• length of Supplemental data including prefix must be 5. Total
required length is 21 for EAN-13 and 16 for EAN-8.
• Prefix for the main body portion of the label for UPCA/UPCE/
EAN13 can be ]E0 or ]E3.
• If the main body prefix for UPCA/UPCE/EAN13 is ]E0, then the
2-digit addon portion of the label must have a prefix of ]E1.
Examples: addon portion is highlighted data is underlined.
UPC-A 2-Digit addon ']E00060992011187]E112'
UPC-E 2-Digit addon ']E00000000998875]E112
'
EAN-8 2-Digit addon ']E400210126]E112'
EAN-13 2-Digit addon ']E01101234567891]E112
'
UPC-A ]E3006099201118712
UPC-E ]E3000000099887512
EAN-13 ]E3110123456789112

Datalogic MAGELLAN 8300 Specifications

General

Read rate (max)	3900 reads/s
Decoding standards	1D, GS1 DataBar
Standard interfaces	Keyboard Wedge, RS-232
USB 2.0 ports quantity	1
Input voltage	100 - 250 V
Product color	Metallic
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	130 mm
