Datalogic MAGELLAN 8300 Product Reference Guide

G-12 Magellan
®
8300/8400
5-Digit Supplemental
• Supplemental data is appended to any EAN base label.
• Prefix must be ASCII characters ']E2'.
• Length of supplemental data including prefix must be 8. Total
required length is 24 for EAN-13 and 19 for EAN-8.
• Prefix for the main body portion of the label for UPCA/UPCE/
EAN13 can be ]E0 or ]E3.
• If the main body prefix for UPCA/UPCE/EAN13 is ]E0, then the
5-digit addon portion of the label must have a prefix of ]E2.
Examples: addon portion is highlighted data is underlined.
UPC-A 5-Digit addon ']E00060992011187]E212345'
UPC-E 5-Digit addon ']E00000000998875]E212345
'
EAN-8 5-Digit addon ']E400210126]E212345
'
EAN-13 5-Digit addon ']E01101234567891]E212345'
UPC-A ]E3006099201118712345
UPC-E ]E3000000099887512345
EAN-13 ]E3110123456789112345

Datalogic MAGELLAN 8300 Specifications

General

Read rate (max)	3900 reads/s
Decoding standards	1D, GS1 DataBar
Standard interfaces	Keyboard Wedge, RS-232
USB 2.0 ports quantity	1
Input voltage	100 - 250 V
Product color	Metallic
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	130 mm
