Datalogic MAGELLAN 8300 Product Reference Guide

G-2 Magellan
®
8300/8400
Datalogic Handheld Data Format Requirements
The following sections describe label transmission formats that are typi-
cally observed in factory configurations of Datalogic handheld scanners.
DataBar Omnidirectional
• Prefix must be ASCII characters ‘R4’
• Check character must be included in label
• Application identifier “01” must follow the prefix and preceed the
base label
• Label length excluding prefix characters must be 16 characters.
• Example: ‘R40101044123456789’
DataBar Expanded
• Prefix must be ASCII characters ‘R4’
• Check character must be included in label
UPC-A
• System number must be included in label data.
• Check digit must be included in label data and is assumed to be cor-
rect.
• Prefix must be an ASCII character 'A' - total length including prefix
must be 13.
• Example: 'A060992011187'.
UPC-A with 2-Digit Supplemental
• System number must be included in label data.
• Check digit must be included in label data and is assumed to be cor-
rect.
• Supplemental data is appended to base label.
• Prefix must be an ASCII character 'A' - total length including prefix
must be 15.
• Example: 'A06099201118712'.

Datalogic MAGELLAN 8300 Specifications

General

Read rate (max)	3900 reads/s
Decoding standards	1D, GS1 DataBar
Standard interfaces	Keyboard Wedge, RS-232
USB 2.0 ports quantity	1
Input voltage	100 - 250 V
Product color	Metallic
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	130 mm
