Datalogic MAGELLAN 8300 Product Reference Guide

EAS Comm Port (Sensormatic
®
systems
Product Reference Guide B-9
EAS Comm Port (Sensormatic
®
systems ONLY)
EAS Deactivator Control Box Connection
Connector Hardware
RJ4
Cable Pinout
Table B-8. EAS Port Cable Pinouts
PIN # FUNCTION DESCRIPTION
1GNDGND
2 +5V Out +5V Out
3 External Read Indicator When configured, signifies good read
4 Audio Out
Intended to drive an external amplifier that
drives and external speaker.

Datalogic MAGELLAN 8300 Specifications

General

Read rate (max)	3900 reads/s
Decoding standards	1D, GS1 DataBar
Standard interfaces	Keyboard Wedge, RS-232
USB 2.0 ports quantity	1
Input voltage	100 - 250 V
Product color	Metallic
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	130 mm
