Datalogic MAGELLAN 8300 Product Reference Guide

Product Reference Guide G-3
UPC-A with 5-Digit Supplemental
• System number must be included in label data
• Check digit must be included in label data and is assumed to be cor-
rect
• Prefix must be an ASCII character 'A' - total length including prefix
must be 18
• Example: 'A06099201118712345'
UPC-A with Code 128 Supplemental
• System number must be included in label data.
• Check digit must be included in label data and is assumed to be cor-
rect.
• Supplemental data is appended to base label.
• Prefix must be an ASCII character 'A' - total length including prefix
must be greater or equal to 19 Code 128 Supplemental codes are
variable length having a minimum of 2 data characters).
• Characters immediately following base label must be of the form
'8100', '8101' or '8102'.
• Example: 'A0609920111878100000951'.
UPC-E
• System number must be included in label data
• Check digit must be included in label data and is assumed to be cor-
rect
• Prefix must be an ASCII character 'E' - total length including prefix
must be 9
• Example: 'E09988750'

Datalogic MAGELLAN 8300 Specifications

General

Read rate (max)	3900 reads/s
Decoding standards	1D, GS1 DataBar
Standard interfaces	Keyboard Wedge, RS-232
USB 2.0 ports quantity	1
Input voltage	100 - 250 V
Product color	Metallic
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	130 mm
