Datalogic MAGELLAN 8300

2-16 Magellan
®
8300/8400
Figure 2-9. Short Shelf Model 8301/8401 Cutout Dimensions
Figure 2-10. Short Shelf Model 8301/8401 Scanner Reference
Dimensions
11.625"
(29.53cm)
min.
Model 8301/8401 (Short)
Minimum Cutout
Dimensions
Model 8301/8401 (Short)
Supports
Max. Radius = 0.25"
(0.635cm) 4x
4.08" (10.36cm)
Liquid
Drainage
Liquid
Drainage
Support Rails
14.00"
(35.6cm)
min.
Model 8301/8401 (Short)
Scanner Reference Dimensions
4.59"
(11.7cm)
4.08"
(10.36cm
± 0.15cm)
5.6"
(14.22cm)
13.85"
(35.19cm ± 0.15cm)
11.5"
(29.21cm ± 0.1cm)
5.19"
(13.2cm)
9.27"
(23.6cm
± 0.2cm)
