Datalogic MAGELLAN 8300 Product Reference Guide

E-2 Magellan
®
8300/8400
Table E-1. Keyboard Model Cross Reference
Model Type I/F ID
Trans-
mission
Protocol
Scancode
Set
Func.
Key
Map
Support
Use
Country
Mode
PC/XT Foreign ALT Mode Wedge A PC/XT Scan Set 1 No No
AT;
PS/2 25-286;
PS/2 30-286;
PS/2 50, 50Z;
PS/2 60,70,80,90,95
Foreign ALT Mode
Wedge B AT/PS2 Scan Set 2 No No
PS/2 25 and 30
Foreign ALT Mode
Wedge C AT/PS2 Scan Set 1 No No
PC/XT U.S. Mode Wedge D PC/XT Scan Set 1 Yes No
AT;
PS/2 25-286;
PS/2 30-286;
PS/2 50, 50Z;
PS/2 60,70,80,90,95
U.S. Mode + specific
country support
Wedge E AT/PS2 Scan Set 2 Yes Yes
PS/2 25 and 30
U.S. Mode
Wedge F AT/PS2 Scan Set 1 Yes No
IBM 3xxx Terminals
(122-key keyboard)
Wedge G AT/PS2 Scan Set 3 Yes No
IBM 3xxx Terminals
(102-key keyboard)
Wedge H AT/PS2 Scan Set 3 Yes No
PS55 5530T with
JAPANESE DOS (TDOS)
Wedge I AT/PS2
Japanese
DOS
Ye s N o
NEC 9801 Wedge J
NEC
9801
NEC 9801 Yes No

Datalogic MAGELLAN 8300 Specifications

General

Read rate (max)	3900 reads/s
Decoding standards	1D, GS1 DataBar
Standard interfaces	Keyboard Wedge, RS-232
USB 2.0 ports quantity	1
Input voltage	100 - 250 V
Product color	Metallic
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	130 mm
