Datalogic MAGELLAN 8300 Product Reference Guide

Keyboard Model Cross Reference
Product Reference Guide E-9
Table E-8. USB Keyboard Function Key Usage Map
ASCII Key Value Usage Name
00 NUL ALT right Make
01 SOH ALT right Break
02 STX F11
03 ETX F12
04 EOT GUI right Make
05 ENQ GUI right Break
06 ACK CTRL right Make
07 BEL CTRL right Break
08 BS BS
09 HT TAB right
0A LF RIGHT arrow (inner keypad)
0B VT TAB left
0C FF Enter (right keypad)
0D CR CR
0E SO INSERT (inner keypad)
0F SI PAGE UP (inner keypad)
10 DLE PAGE DOWN (inner keypad)
11 DC1 HOME (inner keypad)
12 DC2 LEFT arrow (inner keypad)
13 DC3 DOWN arrow (inner keypad)
14 DC4 UP arrow (inner keypad)
15 NAK F6
16 SYN F1
17 ETB F2
18 CAN F3
19 EM F4
1A SUB F5
1B ESC ESC
1C FS F7
1D GS F8
1E RS F9
1F US F10

Datalogic MAGELLAN 8300 Specifications

General

Read rate (max)	3900 reads/s
Decoding standards	1D, GS1 DataBar
Standard interfaces	Keyboard Wedge, RS-232
USB 2.0 ports quantity	1
Input voltage	100 - 250 V
Product color	Metallic
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	130 mm
