Datalogic MAGELLAN 8300 Product Reference Guide

F-4 Magellan
®
8300/8400
IBM Label Slicing
Control
Slice
when nec.
Slice
when nec.
IBM Maximum Label
Slice Length
64 64
IBM USB Scanner
Device Type
Table top
scanner
RS-232 Baud Rate 9600 9600 9600
RS-232 Number of
Data Bits
8 data bits 8 data bits 7 data bits
RS-232 Number of
Stop Bits
1 stop bit 1 stop bit 1 stop bit
RS-232 Parity None Odd Odd
RS-232 Hardware
Control
Disable
Enable
CTS flow
RS-232 Intercharac-
ter Delay
None None
RS-232 Software
Flow Control
Disable Disable Disable
RS-232 Host Echo Disable Disable
RS-232 Host Echo
Quiet Interval
10ms 10ms
RS-232 Ignore Host
Commands
Do not
ignore
Do not
ignore
Do not
ignore
Do not
ignore
Do not
ignore
Do not
ignore
RS-232 TTL
Normal
RS-232
Normal
RS-232
RS-232 TTL Invert No invert No invert
RS-232
Wincor-
Nixdorf
RS-232
Single
Cable
Keybd.
Wedge
IBM IBM USB

Datalogic MAGELLAN 8300 Specifications

General

Read rate (max)	3900 reads/s
Decoding standards	1D, GS1 DataBar
Standard interfaces	Keyboard Wedge, RS-232
USB 2.0 ports quantity	1
Input voltage	100 - 250 V
Product color	Metallic
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	130 mm
