Figure 2-20. Cable Routing
Scanner
AC Power
Switch
(recommended)
AC/DC
Power
Supply
AC Power
To EAS System
Scanner
Interface
Cable
Scale
Interface
Cable
(Scanner/Scale)
Optional
Remote Scale
Display Cable
(optional
Scanner/Scale)
POS Terminal, Printer &
Cash Drawer
Remote
Display
Keyboard
