Page #72 background image
2-40 Magellan
®
8300/8400
6. Power-up the scanner or scanner/scale by connecting the power cord
to an AC power outlet. Wait for the unit to complete the Self test
routine (10 seconds maximum). Successful scanner power-up is sig-
nified by any or all of the following:
- Facet wheel shows movement
- Lasers turn on
- Status LED(s) turn on
- Speaker sounds tone(s)
- Remote display [if present] shows message
- A single red dot is visible on the 7-segment display
7. Power-up the POS terminal. Verify that scanning, deactivation and
weighing functions are operational and that data is properly com-
municated between the scanner and your POS system. (Scan, deac-
tivate and weigh a few items.) If problems are encountered, refer to
Chapter 4, Problem Isolation.
8. You have now completed installation and system integration of the
scanner or scanner/scale. At this point, the scale must be calibrated
and certified in accordance with the requirements of your state and/
or local requirements. Refer to Chapter 5, Calibration, for cali-
bration procedures.
