3-10 Magellan

8300/8400

With the scanner/scale powered-up and at operating temperature:

1. Remove everything from the weighing surface of the scanner/scale.

2. Press the Scale Zero Push Button. (See Figure 1-1).

3. The Zero

light will turn on and the display will show 0.00 lb

(0.000 kg). If it does not, see Chapter 4, Problem Isolation.

4. You have completed the scale zeroing function.

Calibrating the Scale

The second adjustment, calibration, defines and sets a standard reference

weight range against which all product weights are compared. If your scale

is set for weighing in pounds, this range is 0 - 30 pounds, and, if your scale

is set for weighing in kilograms, the range is 0 - 15 kilograms. The scale

must be calibrated upon initial installation, whenever the scale cannot be

zeroed, when the scale diagnostics indicate a calibration error, when the

weighing measure (pounds or kilograms) is changed, or when the scale

module has been replaced.

Normally, once the scale has been calibrated, the calibration must be veri-

fied and/or approved by a local regulatory body. In many areas of the

United States, the scale calibration switch must be sealed before being

placed into service. Consult the agency responsible for regulating weigh-

ing devices in your area to ensure that you are meeting all legal and regula-

tory requirements. Chapter 5, Calibration, describes the calibration

sequence and verification process.

Calibration can only be performed if the tamper seal that secures access to

the Calibration Switch is broken and the switch cover is removed. Break-

ing the seal may legally render the scale inoperable until it has been recerti-

fied and a new seal attached. Consult your local regulations before

removing the calibration seal if you are unsure of the legal requirements.

Although the scale will physically continue to weigh products, a broken

seal may require recertification by a proper authority as designated by your

local laws.

1. Zero light operation is configurable.
