MATRIX 300N™ REFERENCE MANUAL
102
6
6.3.2 Matrix 300N 4x1 (6 mm models) 2D Codes
Data Matrix 0.19 mm (7.5 mils)
CONDITIONS:
Hardware Settings
Code Symbology
Data Matrix ECC 200
Code Resolution
0.19 mm (7.5 mils)
Tilt Angle
45°
Skew Angle
0°
Focusing Distance (mm)
60
Software Parameters
Illuminator Lighting
Very High Power Strobed
481-xxx MLT-DPM
LED Group
Peripheral
Exposure Time (µs)
380
Gain
23
Horizontal Reading Width
in
1.5 2 2.5 3
0
.5
1
-.5
-1
1.5
-1.5
-2
mm
Reading Distance
2
+15
-15
-0.6
+0.6
in
mm
Horizontal
Reading Width
Max FOV
H
Max FOV
V
Reading Distance
Due to the "fisheye" effect of the wide angle
6 mm lens, the reading area for higher resolution
codes is limited to the central zone of the Vertical
Field of View.
For these applications, Image Cropping is
recommended above and below the central zone
of the Vertical FOV, limiting image acquisition to
the effective reading area and therefore
increasing frame rate and reducing overall image
processing time. See par. 7.2.8.
± 15 mm ≈ 550 pixels
1. Drag top of box to set
x,y coordinates  0,236
2. Drag bottom of box to set
vertical window dimensions  550 pixels

Datalogic Matrix 300N Specifications

General

Type	Barcode module bar barcode readers
Sensor type	CMOS
Scanner type	1D/2D
Yaw reading angle	0 - 24 °
Optical sensor resolution	1024 pixels
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Input voltage	10 - 30 V
Power consumption (typical)	5 W
Connectivity technology	Wired
Certification	AIM DPM, ISO/IEC 15415, ISO/IEC 15416, ISO/IEC 16022, ISO/IEC 18004, AS9132A
Product color	Blue, Metallic
Housing material	Aluminium, Plastic
International Protection (IP) code	IP67
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	54 mm
Width	75 mm
Height	62 mm
Weight	238 g
