Datalogic Matrix 300N Reference Manual

vi
REFERENCES
CONVENTIONS
This manual uses the following conventions:
"User" refers to anyone using a Matrix 300N reader.
"Reader" refers to the Matrix 300N reader.
"You" refers to the System Administrator or Technical Support person using this manual to
install, configure, operate, maintain or troubleshoot a Matrix 300N reader.
REFERENCE DOCUMENTATION
For further details refer to: the DL.CODE™ Help On Line, DL.CODE User’s Guide, Matrix
Reading Methods, provided as supplementary documentation on the DL.CODE mini-DVD
(downloaded .zip file or mini-DVD accessory).
SUPPORT THROUGH THE WEBSITE
Datalogic provides several services as well as technical support through its website. Log on
to www.datalogic.com and click on the Industrial Automation links for further information:
 PRODUCTS – FIXED INDUSTRIAL BARCODE READERS
Select your product from the links on the Fixed Industrial Barcode Readers page. The
product page describes specific Info, Features, Applications, Models, Accessories, and
Downloads including documentation, software drivers, and utility programs.
 SUPPORT & SERVICES – INDUSTRIAL AUTOMATION
Several links from the Industrial Automation list take you to additional services such as:
Service Program which contains Maintenance Agreements and Warranty Extensions;
Repair Centers; On-Line RMA Return Material Authorizations; Technical Support through
email or phone; Downloads for additional downloads.
PATENTS
See www.patents.datalogic.com for patent list.
This product is covered by one or more of the following patents:
Design patents: EP002197715
Utility patents: EP0996284B1, EP0999514B1, EP1014292B1, EP1128315B1,
EP1396811B1, EP1413971B1, JP4435343B2, JP4571258B2, US6512218, US6616039,
US6808114, US6997385, US7053954, US7387246, US8058600, US8368000, US8743263

Datalogic Matrix 300N Specifications

General

Type	Barcode module bar barcode readers
Sensor type	CMOS
Scanner type	1D/2D
Yaw reading angle	0 - 24 °
Optical sensor resolution	1024 pixels
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Input voltage	10 - 30 V
Power consumption (typical)	5 W
Connectivity technology	Wired
Certification	AIM DPM, ISO/IEC 15415, ISO/IEC 15416, ISO/IEC 16022, ISO/IEC 18004, AS9132A
Product color	Blue, Metallic
Housing material	Aluminium, Plastic
International Protection (IP) code	IP67
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	54 mm
Width	75 mm
Height	62 mm
Weight	238 g
