Datalogic Matrix 300N Reference Manual

MATRIX 300N™ REFERENCE MANUAL
154
10
PHYSICAL FEATURES
Connector position 0°
Connector position 90°
Dimensions
95 x 54 x 43 mm (3.7 x 2.1 x 1.7 in.)
75 x 54 x 62 mm (3.0 x 2.1 x 2.4 in.)
Weight
about 238 g. (8.4 oz.)
Material
Aluminium
SOFTWARE FEATURES
Readable Code Symbologies
1-D and stacked
2-D
POSTAL
 PDF417 Standard and Micro PDF417
 Code 128 (GS1-128)
 Data Matrix ECC 200
(Standard, GS1 and Direct Marking)
 Australia Post
 Royal Mail 4 State Customer
 Code 39 (Standard and Full ASCII)
 Code 32
 MSI
 QR Code
(Standard and Direct Marking)
 Micro QR Code
 Kix Code
 Japan Post
 PLANET
 POSTNET
 POSTNET (+BB)
 Intelligent Mail
 Swedish Post
 Standard 2 of 5
 MAXICODE
 Aztec Code
 Matrix 2 of 5
 Interleaved 2 of 5
 Codabar
 Code 93
 Pharmacode
 EAN-8/13 - UPC-A/E
(including Addon 2 and Addon 5)
 GS1 DataBar Family
 Composite Symbologies
Operating Mode
CONTINUOUS, ONE SHOT, PHASE MODE, PACKTRACK
Configuration Methods
X-PRESS Human Machine Interface
Windows-based SW (DL.CODE) via Ethernet link
Serial Host Mode Programming sequences
Parameter Storage
Permanent memory (Flash)
CODE QUALITY METRICS
Standard
Supported Symbologies
ISO/IEC 16022
Data Matrix ECC 200
ISO/IEC 18004
QR Code
AIM DPM
Data Matrix ECC 200, QR Code
ISO/IEC 15416
Code 128, Code 39, Interleaved 2 of 5, Codabar, Code 93, EAN-8/13,
UPC-A/E
USER INTERFACE
LED Indicators
Power, Ready, Good; Trigger; Com, Status, (Ethernet Network); Good
Read (Green Spot), No Read (Red Spot)
Keypad Button
Configurable via DL.CODE
Beeper
Configurable via DL.CODE

Datalogic Matrix 300N Specifications

General

Type	Barcode module bar barcode readers
Sensor type	CMOS
Scanner type	1D/2D
Yaw reading angle	0 - 24 °
Optical sensor resolution	1024 pixels
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Input voltage	10 - 30 V
Power consumption (typical)	5 W
Connectivity technology	Wired
Certification	AIM DPM, ISO/IEC 15415, ISO/IEC 15416, ISO/IEC 16022, ISO/IEC 18004, AS9132A
Product color	Blue, Metallic
Housing material	Aluminium, Plastic
International Protection (IP) code	IP67
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	54 mm
Width	75 mm
Height	62 mm
Weight	238 g
