Datalogic Matrix 300N Reference Manual

SOFTWARE CONFIGURATION
131
7
Restore Factory Defaults
In order to return a device to its absolute Factory default parameters (for example device
replacement) it is necessary to use the Restore Factory Defaults command. You will be
prompted to confirm.
All Environment parameters will be restored to Factory default values and any existing
configurations stored on the device will be erased. The device will be reset and therefore
start in run mode with the factory default configuration.
7.2.3 Auto Calibration
DL.CODE provides the Image Auto-Setup tool to maximize the reading performance by
tuning the acquisition parameters (photometry) automatically. By selecting the Image Auto-
Setup tool from the Image Setup step, the following window appears:
Figure 69 – Image Auto-Setup
Select the Static or Dynamic Self-Tuning option; Start Autolearn and Apply to the Image
Setup. The Image Setup window works interactively so that you can see the results of the
parameter setting changes as well as the decoding results (Results panel). When switching
to the Code Setup step you can also see the decoding results displayed on the image.
Figure 70 – Decoding Results OK

Datalogic Matrix 300N Specifications

General

Type	Barcode module bar barcode readers
Sensor type	CMOS
Scanner type	1D/2D
Yaw reading angle	0 - 24 °
Optical sensor resolution	1024 pixels
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Input voltage	10 - 30 V
Power consumption (typical)	5 W
Connectivity technology	Wired
Certification	AIM DPM, ISO/IEC 15415, ISO/IEC 15416, ISO/IEC 16022, ISO/IEC 18004, AS9132A
Product color	Blue, Metallic
Housing material	Aluminium, Plastic
International Protection (IP) code	IP67
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	54 mm
Width	75 mm
Height	62 mm
Weight	238 g
