Datalogic Matrix 300N Reference Manual

SOFTWARE CONFIGURATION
139
7
7.2.8 Image Cropping
In some applications, the Image Cropping feature in DL.CODE can help to increase decoding
and result performance. Image cropping is performed from the Image Setup tab by clicking
on the Add Cropping Region icon as shown below.
In Matrix 300N the frame rate is dependent on the number of rows and columns in the
defined window. Image cropping allows reducing the Image processing area from the full
FoV to a smaller area where codes are present. By excluding portions of the FoV, processing
time is reduced.

Datalogic Matrix 300N Specifications

General

Type	Barcode module bar barcode readers
Sensor type	CMOS
Scanner type	1D/2D
Yaw reading angle	0 - 24 °
Optical sensor resolution	1024 pixels
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Input voltage	10 - 30 V
Power consumption (typical)	5 W
Connectivity technology	Wired
Certification	AIM DPM, ISO/IEC 15415, ISO/IEC 15416, ISO/IEC 16022, ISO/IEC 18004, AS9132A
Product color	Blue, Metallic
Housing material	Aluminium, Plastic
International Protection (IP) code	IP67
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	54 mm
Width	75 mm
Height	62 mm
Weight	238 g
