Datalogic Matrix 300N Reference Manual

MATRIX 300N™ REFERENCE MANUAL
140
7
After clicking the Add Cropping Region icon, a blue border appears which by default is equal
to the FoV.
By dragging the edges with the mouse (resizing) you can crop the image to a specific
location where codes are present. The numbers in the blue boxes refer to pixel references.
x,y coordinates of
upper left corner of
Cropping Region
number of pixels in
vertical Cropping
Region (Height)

Datalogic Matrix 300N Specifications

General

Type	Barcode module bar barcode readers
Sensor type	CMOS
Scanner type	1D/2D
Yaw reading angle	0 - 24 °
Optical sensor resolution	1024 pixels
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Input voltage	10 - 30 V
Power consumption (typical)	5 W
Connectivity technology	Wired
Certification	AIM DPM, ISO/IEC 15415, ISO/IEC 15416, ISO/IEC 16022, ISO/IEC 18004, AS9132A
Product color	Blue, Metallic
Housing material	Aluminium, Plastic
International Protection (IP) code	IP67
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	54 mm
Width	75 mm
Height	62 mm
Weight	238 g
