STEP 5 – INSTALLING DL.CODE CONFIGURATION PROGRAM
DL.CODE is a Datalogic reader configuration tool providing several important advantages:
Intuitive Graphical User Interface for rapid configuration;
Defined configuration directly stored in the reader;
Discovery and IP address setting features to facilitate remote configuration
Device Monitoring
To install DL.CODE:
1. On the PC that will be used for configuration, (running Windows XP, Vista, or 7), download
the DL.CODE mini-DVD .zip file. Extract the files maintaining the folder structure and run
the start.hta file to access the installation pop-up. Click on the Install DL.CODE X.x link to
run the installation program and follow the installation procedure.
2. When the installation is complete the DL.CODE entry is created in the Start>Programs
bar under “Datalogic” as well as a desktop icon. Double-click the desktop icon to run it.
This configuration procedure assumes a laptop computer, running DL.CODE, is connected to
a factory default reader through the Ethernet port.
Device Discovery
The User Interface opens and displays a list of all the devices belonging to the Local Area
Network. DL.CODE has a discovery feature to accomplish this task.
Figure 8 – Device Discovery
