Datalogic Matrix 300N Reference Manual

CBX ELECTRICAL CONNECTIONS
61
4
4 CBX ELECTRICAL CONNECTIONS
All Matrix 300N models can be connected to a CBX connection box through one of the
available CAB-DSxx-S accessory cables. These accessory cables terminate in an M12 17-
pin connector on the Matrix 300N side and in a 25-pin male D-sub connector on the CBX
side.
We recommend making system connections through one of the CBX connection boxes since
they offer the advantages of easy connection, easy device replacement, opto-isolated
outputs (Outputs 1 and 2), and filtered reference signals.
NOTE: If you require direct wiring to the reader the connections are the
same as shown in this chapter with the exception of the digital Outputs. Direct
wiring details are indicated in Appendix A
The table below gives the pinout of the CBX100/500 terminal block connectors. Use this
pinout when the Matrix 300N reader is connected by means of the CBX100/500:
CBX100/500 Terminal Block Connectors
Input Power
Vdc
Power Supply Input Voltage +
GND
Power Supply Input Voltage -
Earth
Protection Earth Ground
Inputs
+V
Power Source – External Trigger
I1A
External Trigger A (polarity insensitive)
I1B
External Trigger B (polarity insensitive)
-V
Power Reference – External Trigger
+V
Power Source – Inputs
I2A
Input 2 A (polarity insensitive)
I2B
Input 2 B (polarity insensitive)
-V
Power Reference – Inputs
Outputs
+V
Power Source - Outputs
-V
Power Reference - Outputs
O1+
Output 1 + opto-isolated and polarity sensitive
O1-
Output 1 - opto-isolated and polarity sensitive
O2+
Output 2 + opto-isolated and polarity sensitive
O2-
Output 2 - opto-isolated and polarity sensitive
O3A
Output 3 non opto-isolated (only available through CBX500)
Auxiliary Interface
TX
Auxiliary Interface TX
RX
Auxiliary Interface RX
SGND
Auxiliary Interface Reference
ID-NET
REF
Network Reference
ID+
ID-NET network +
ID-
ID-NET network -
Shield
Network Cable Shield
Main Interface
RS232
RS422 Full-Duplex
TX
TX+
RX
*RX+
-
TX-
-
*RX-
SGND
SGND
* Do not leave floating, see par. 4.2.2 for connection details.

Datalogic Matrix 300N Specifications

General

Type	Barcode module bar barcode readers
Sensor type	CMOS
Scanner type	1D/2D
Yaw reading angle	0 - 24 °
Optical sensor resolution	1024 pixels
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Input voltage	10 - 30 V
Power consumption (typical)	5 W
Connectivity technology	Wired
Certification	AIM DPM, ISO/IEC 15415, ISO/IEC 15416, ISO/IEC 16022, ISO/IEC 18004, AS9132A
Product color	Blue, Metallic
Housing material	Aluminium, Plastic
International Protection (IP) code	IP67
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	54 mm
Width	75 mm
Height	62 mm
Weight	238 g
