xii
Matrix 300N™
Manual Adjustable Focus Models
Figure B
1
2
3
4
9
Device Class and Warning Labels
Bracket Mounting Holes (4)
Good Read LED (green)
Lens Cover
Power - Serial Interfaces - I/O Connector
Ethernet Connector
No Read LED (red)
8
Internal Illuminator
5
HMI X-PRESS Interface
Aiming System Laser Pointers
12
6
Lens
Ethernet Connection LED
7
Focus Adjustment Screw
10
11
13
Power On LED
14
2
1
2
13
14
Connector block
rotates to 90° position
1
3
5
9
12
4
11
10
8
7
6
