Enter/Exit Programming Mode
248
PowerScan™ PD9531-AR/PBT9501-AR/PM9501-AR
RS-485 Slave Maximum Address
Specifies the maximum address that can be set for a Cradle in an RS-485
network.
Slave Maximum Address
To configure this feature, scan the ENTER/EXIT
PROGRAMMING MODE bar code above, then the bar
code at left followed by four digits from the Alpha-
numeric characters in
Appendix D, Keypad
rep-
resenting your desired character(s). End by scanning
the ENTER/EXIT ba
r code again.
Make a mistake? Scan the CANCEL bar code to abort
an
d not save the entry string. You can then start
again at the beginning.
CANCEL
The maximum number of cradles in a single network is 16 (including the Master if
present). All cradles in the system must have different addresses.
RS-485 Network Working Mode
Specifies the selection available for Cradle working mode in an RS-485 net-
work.
Disable Network
Enable RS-485 Slave
Enable RS-485 Master
To Next Page
