Enter/Exit Programming Mode
254
PowerScan™ PD9531-AR/PBT9501-AR/PM9501-AR
Enable/Disable Buttons
This feature offers the ability to enable or disable the keypad.
Figure 6. PowerScan 9501-AR Keypad Models
16-key keypad
4-key keypad
Key Programming
All keys enabled
DEFAULT
All keys disabled
Enable a combination of keys (4-key models only)
To configure this feature, scan the ENTER/EXIT PRO-
GRAMMING MODE bar code above, then the bar code
a
t left followed by 4 digits from the Alphanumeric
characters in
Appendix D, Keypad
.
4-key models only
: The last 3 digits must always be 0;
the 4 bits of the first digit must be 1 if the corre-
sponding key is enabled; the four bits represent,
s
tarting from the highest: Arrow Up, F2, F1, Arrow
Down. End by scanning the ENTER/EXIT bar code
again.
Make a mistake? Scan the CANCEL
bar code to abort
and not save the entry string. You can then start
again at the beginning.
CANCEL
