Data Editing
Product Reference Guide
299
Character Conversion
Character conversion is an eight byte configuration item. The eight bytes are
4 character pairs represented in hexadecimal ASCII values. The first charac-
ter in the pair is the character that will be converted. The second character in
t
he pair is the character to convert to. If the character to convert in a pair is
FF, then no conversion is done.
For example, if you have the character conversion configuration item set to
the following: 41423132FF
FFFFFF
The first pair is 4142 or AB (41 hex is an ASCII capital A, 42 hex is an ASCII
capital B) and the second pair is 3132 or 12 (31 hex is an ASCII 1, 32 is an
ASCII 2). The other two pairs are FFFF and FFFF.
With the label, AB12BA21, it would look
as follows after the character con-
version: BB22BB22.
The A characters were converted to B c
haracters and the 1 characters were
converted to 2 characters. Nothing is done with the last two character pairs,
since they are all FF.
To set Character Conversion:
1. Go to page 68 and scan the ENTER/EXIT bar code.
2. Scan the “Configure Character Conversion” bar code.
3. Determine the desired string. Sixteen p
ositions must be determined as
in the above example. Next, turn to the ASCII Chart on the inside back
cover of this manual and find the equivalent hex digits needed to fulfill
th
e string.
4. Turn to Appendix D, Keypad and scan the bar codes representing the
hex characters determined in the previous step.
5. Scan the ENTER/EXIT bar code to
exit Programming Mode.
If less than the expected string of 16 characters are selected, scan the
ENTER/EXIT bar code twice to accept the selections and exit Program-
ming Mode.
