Product Reference Guide
313
Appendix A
Technical Specifications
The tables that follow contain Physical and Performance Characteristics,
User Environment and Regulatory information.
Table 47 provides Standard
Cable Pinouts.
Table 46. Technical Specifications
Item Description
Physical Characteristics
Dimensions
Height: 212 mm
Length: 110 mm
Width: 74 mm
Weight (without cable)
PD9531-AR: 400 g (without cable)
PM9501-ARXX, PBT9501-AR: 460 g
PM9501-DARXX, PM9501-DKARXX: 485 g
Electrical Characteristics
PD9531-AR models
Voltage & Current
Input Voltage 4,5 to 30 Vdc
Input Current
Operating (max): 500 mA
Idle/Standby (typical) 120 mA
PBT9501-AR and PM9501-AR models
Battery Type Li-Ion battery pack
Charge time for full
charge
from full dis-
charge
4, 5 hours with external power supply adapter
a
a. Charge Times are much lower when battery is within daily typical operating condition.
Typical 10 hours with Host power (in this case no supply
adapter is needed)
a
Operating autonomy
(continuous reading)
40,000 + reads (typical, @25°C)
Cradle consumption and
DC
input supply range
Volt 10-30 VDC; Power <8 W
b
b. Typical input current measured under factory default configuration.
;
Max 500 mA when in host/bus powered mode
b
.
