Datamax H Class User Manual

53
UHF SETTINGS
*
Sets UHF tag parameters:
TAG TYPE Sets the tag type:
EPC 0
EPC 0+ MATRICS
EPC 0+ IMPINJ
EPC 1
UCODE EPC 1.19
EM 4022/1222
GEN 2
TAG DATA
SIZE
Sets the tag data size:
96-BIT
64-BIT
POWER
ADJUST
KILL CODE B3 B2 B1 B0
00 00 00 00
ACCESS CODE B3 B2 B1 B0
00 00 00 00
GEN 2 LOCK
ACTION
Sets the lock level: NONE, PERMALOCK, PWD-READ/WRITE, and BOTH
LOCK AFTER
WRITE *
ENABLED
DISABLED
RETRY
ATTEMPTS *
Sets the number of retry attempts (0 - 9), where:
3 Is the Default Setting.
PERFORM
CALIBRATION *
Automatically establishes the tag to transducer distance setting and nominal RFID
power requirements.
SET DEFAULTS
*
Returns the RFID option settings to the factory default values.
GPIO PORT
Configures the General Purpose Input / Output card to allow the printer to work in
concert with external devices, as follows:
GPIO DEVICE
Sets the GPIO option to work with a specific type of device, where:
DISABLED Disables the GPIO Port.
APPLICATOR Enables the GPIO to work with a label applicator.
BARCODE
VERIFIER
Enables the GPIO work with a bar code verifier.
START OF
PRINT *
Selects the type of input signal needed to initiate the Start of Print (SOP) process,
where:
LOW PULSE A low incoming pulse (approximately 30 milliseconds long) will trigger the SOP.
HIGH PULSE A high incoming pulse (approximately 30 milliseconds long) will trigger the SOP.
ACTIVE LOW SOP signal must go ‘low’ for at least 50 milliseconds to initiate printing.
ACTIVE HIGH SOP signal must go ‘low’ for at least 50 milliseconds to initiate printing.
EDGE An edge transition triggers SOP.
