REG:2F:10 – EVC_STO – SFD Timeout Error Counter
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
-
-
-
-
EVC_STO
-
-
-
-
0
The bits of the EVC_STO register are described below:
Field
Description of fields within Sub-Register 0x2F:10 – SFD Timeout Error Counter
EVC_STO
reg:2F:10
bits:11–0
SFD timeout errors Event Counter. The EVC_STO field is a 12-bit counter of SFD Timeout Error
events. This is essentially a count of the reporting of RXSFDTO events in Register file: 0x0F –
System Event Status Register.
NB: For this counter to be active, counting needs to be enabled by the setting the EVC_EN bit
in Sub-Register 0x2F:00 – Event Counter Control.
-
bits:15–12
The remaining bits of this register are reserved.
7.2.48.9 Sub-Register 0x2F:12 – Preamble Detection Timeout Event Counter
ID
Length
(octets)
Type
Mnemonic
Description
2F:12
2
RO
EVC_PTO
Preamble Detection Timeout Event Counter
Register file: 0x2F – Digital Diagnostics Interface, sub-register 0x12 is the Preamble Timeout Event Counter.
REG:2F:12 – EVC_PTO – Preamble Detection Timeout Event Counter
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
-
-
-
-
EVC_PTO
-
-
-
-
0
The bits of the EVC_PTO register are described below:
Field
Description of fields within Sub-Register 0x2F:12 – Preamble Detection Timeout Event Counter
EVC_PTO
reg:2F:12
bits:11–0
Preamble Detection Timeout Event Counter. The EVC_PTO field is a 12-bit counter of
Preamble detection Timeout events. This is essentially a count of the reporting of RXPTO
events, in Register file: 0x0F – System Event Status Register.
NB: For this counter to be active, counting needs to be enabled by the setting the EVC_EN bit
in Sub-Register 0x2F:00 – Event Counter Control.
-
bits:15–12
The remaining bits of this register are reserved.
7.2.48.10 Sub-Register 0x2F:14 – RX Frame Wait Timeout Event Counter
ID
Length
(octets)
Type
Mnemonic
Description
2F:14
2
RO
EVC_FWTO
RX Frame Wait Timeout Counter
Register file: 0x2F – Digital Diagnostics Interface, sub-register 0x14 is the RX Frame Wait Timeout Event
Counter.
