IPv4 Routing | 675
Related
Commands
Example
Figure 24-22. show ip route summary Command Example
show ip route summary
c e s
View a table summarizing the IP routes in the switch.
Syntax
show ip route summary
Command Modes
EXEC
EXEC Privilege
Command
History
Example
Figure 24-23. show ip route summary Command Example
ip prefix-list Enter the CONFIGURATION-IP PREFIX-LIST mode and configure a
prefix list.
show ip prefix-list summary Display a summary of the configured prefix lists.
FTOS#show ip route list test
Codes: C - connected, S - static, R - RIP,
B - BGP, IN - internal BGP, EX - external BGP,LO - Locally Originated,
O - OSPF, IA - OSPF inter area, N1 - OSPF NSSA external type 1,
N2 - OSPF NSSA external type 2, E1 - OSPF external type 1,
E2 - OSPF external type 2, i - IS-IS, L1 - IS-IS level-1,
L2 - IS-IS level-2, IA - IS-IS inter area, * - candidate default,
> - non-active route, + - summary route
Gateway of last resort is not set
Destination Gateway Dist/Metric Last Change
----------- ------- ----------- -----------
R 2.1.0.0/24 via 2.1.4.1, Gi 4/43 120/2 3d0h
R 2.1.1.0/24 via 2.1.4.1, Gi 4/43 120/2 3d1h
R 2.1.2.0/24 via 2.1.4.1, Gi 4/43 120/1 3d0h
R 2.1.3.0/24 via 2.1.4.1, Gi 4/43 120/1 3d1h
C 2.1.4.0/24 Direct, Gi 4/43 0/0 3d1h
Version 8.1.1.0 Introduced on E-Series ExaScale
Version 7.6.1.0 Introduced on S-Series
Version 7.5.1.0 Introduced on C-Series
pre-Version 6.1.1.0 Introduced for E-Series
FTOS>show ip route summary
Route Source Active Routes Non-active Routes
connected 17 0
static 3 0
ospf 100 1368 2
Intra-area: 762 Inter-area: 1 External-1: 600 External-2: 5
Total 1388 2
Total 1388 active route(s) using 222440 bytes
Total 2 non-active route(s) using 128 bytes
FTOS>
