Layer 2 | 877
Command Modes
EXEC
EXEC Privilege
Command
History
Example
Figure 30-1. show cam maccheck linecard Command Output Example
Usage
Information
Use this command to check various flags associated with each MAC address in the CAM.
Figure 30-1 shows information for two MAC addresses. The second entry is for MAC address
00:00:a0:00:00:00 (leading 0s are not shown), which is shown as learned on VLAN ID 4094
(0xfff), as shown below in Figure 30-2 and Figure 30-3. Above, “STATIC_BIT=0” means that
the address is dynamically learned.
When an entry is listed as STATIC_BIT=1, its HIT_SA is 0, which signifies that this address is
not getting continuously learned trough traffic. The HIT_DA is set when a new learn happens, and
after the first age sweep, it gets reset.
Example
Figure 30-2. show mac-address-table Command Output Example
Example
Figure 30-3. show cam mac linecard Command Output Example
Version 7.6.1.0 Introduced on C-Series
FTOS#show cam maccheck linecard 2 port-set 0
Dumping entries. From 0 to 16383.
Progress . marks 100 memory table entries.
............................Index 5576 (0x15c8) has valid entries (H: 2b9, E: 0)
<MAC_ADDR=0xffffffffffff,VLAN_ID=0xfff,PRI=0,CPU=0,DST_DISCARD=0,SRC_DISCARD=0,SCP
=0,TGID_LO=0,PORT_TGID=0,TGID_PORT=0,T=0,TGID_HI=0,L2MC_PTR=0,MODULE_ID=0,REMOTE_T
RUNK=0,L3=0,MAC_BLOCK_INDEX=0,STATIC_BIT=1,RPE=0,MIRROR=0,VALID=1,EVEN_PARITY=0,HI
TDA=0,HITSA=0>
..........Index 6592 (0x19c0) has valid entries (H: 338, E: 0)
<MAC_ADDR=0xa0000000,VLAN_ID=0xffe,PRI=0,CPU=0,DST_DISCARD=0,SRC_DISCARD=0,SCP=0,T
GID_LO=0,PORT_TGID=0,TGID_PORT=0,T=0,TGID_HI=0,L2MC_PTR=0,MODULE_ID=0x10,REMOTE_TR
UNK=0,L3=0,MAC_BLOCK_INDEX=0,STATIC_BIT=0,RPE=0,MIRROR=0,VALID=1,EVEN_PARITY=1,HIT
DA=1,HITSA=1>
!-------------output truncated-------------------!
FTOS#show mac-address-table
VlanId Mac Address Type Interface State
4094 00:00:a0:00:00:00 Dynamic Gi 2/0 Active
!-------------output truncated-------------------!
FTOS#show cam mac linecard 2 port-set 0
VlanId Mac Address Region Interface
0 ff:ff:ff:ff:ff:ff STATIC 00001
4094 00:00:a0:00:00:00 DYNAMIC Gi 2/0
!-------------output truncated-------------------!
