Dell Networking 7048 User Manual

1176 Managing IPv4 and IPv6 Multicast
Multicast Admin Boundary Configuration
The definition of an administratively scoped boundary is a way to stop the
ingress and egress of multicast traffic for a given range of multicast addresses
on a given routing interface. Use the Admin Boundary Configuration
page to
configure a new or existing administratively scoped boundary. To see this
page, you must have configured a valid routing interface and multicast.
To display the page, click IPv4 Multicast
→ Multicast → Admin Boundary
Configuration in the navigation panel.
Figure 42-12. Multicast Admin Boundary Configuration

Dell Networking 7048 Specifications

General

Brand	Dell
Model	Networking 7048
Category	Switch
Language	English
