Hardware Overview 91
The following images show the back panel of the PowerConnect 7000 Series
switches.
Figure 3-8. PC7024, PC7024F, and PC7048 Back Panel
Figure 3-9. PC7024P and PC7048P Back Panel
Figure 3-10. PC7048R Back Panel
Dual 10G Slots for SFP+, 10GBase-T,
or Stacking/10GbE Modules
AC Power
Receptacle
Redundant DC Power
Supply Receptacle
Fan Vents
AC Power
Receptacle
External DC Power
Supply Receptacle
Fan Vents
Dual 10G Slots for SFP+, 10GBase-T,
or Stacking/10 GbE Modules
AC Power
Receptacle
Fan Trays
AC Power
Receptacle
Dual 10G Slots for SFP+, 10GBase-T,
or Stacking/10GbE Modules
