Removing and Installing System Components | 169
System-Board Assembly
Removing a Dummy System-Board Tray
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came with
the product.
1 Remove the screw that secures the retaining latch. See Figure 3-14.
2 Press the retaining latch and slide the dummy system-board tray out of
the chassis. See Figure 3-14.
Figure 3-14. Removing and Installing a Dummy System-Board Tray
