Power and System Board Indicator Codes
The LEDs on the system front panel and back panel display status codes
during system startup. For location of the LEDs on the front panel, see
Figure 1-1 for 3.5” hard drive and Figure 1-4 for 2.5” hard drive systems. For
location of the LEDs on the back panel, see Figure 1-14 and Figure 1-15.
Table 1-3 lists the status associated with the status codes.
Table 1-3. Status Indicator Codes
Component
Indicator
Condition
Power-on
indicator
(A bi-color LED
on power button)
Green
Solid
Power On (S0)
Amber
Off
Green
Off
BMC critical condition event in Power
Off mode (S4/S5)
Amber
Blinking
Green
Off
BMC critical condition event in Power
On mode (S0)
Amber
Blinking
System
identification
indicator
Steady Blue
IPMI via Chassis Identify Command On
or ID Button Press ID On
Blinking Blue
Only IPMI via Chassis Identify
Command Blink On
Off
IPMI via Chassis Identify Command Off
or ID Button Press ID Off
