176 | Removing and Installing System Components
Installing the Heat Sink
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came with
the product.
1 Using a clean lint-free cloth, remove the thermal grease from the heat
sink.
2 Apply new thermal grease evenly to the center of the top of the new
processor.
CAUTION: Using excess thermal grease can cause grease to contact the
processor shield, which can cause contamination of the processor socket.
3 Place the heat sink on the processor. See Figure 3-19.
4 Using a Phillips screwdriver, tighten the four heat-sink retention screws.
5 Replace the system-board assembly. See "Installing a System-Board
Assembly" on page 171.
Processors
This system board supports dual Intel E5-2600 or E5-2600 v2 processor
series, which is up to 135W, 3.5GHz and 12 cores, based on Intel Patsburg
PCH chipset.
Removing a Processor
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came with
the product.
1 Remove the system-board assembly. See “Removing a System-Board
Assembly" on page 170.
