Dell PowerEdge C6220 II - Cable Routing for LSI 9265-8 I Card (1 U Node)

Removing and Installing System Components | 199
10 Replace the four screws that secure the LSI 9265-8i card assembly.
11 Install the system-board assembly. See "Installing a System-Board
Assembly" on page 171.
Cable Routing for LSI 9265-8i Card (1U Node)
1 Connect the mini-SAS cable to the LSI 9265-8i card, and connect the
other end of the cable to the corresponding connector on the system
board.
2 Connect the mini-SAS&SGPIO cable to the LSI 9265-8i card, and
connect the other end of the cable to the corresponding connectors on
the system board. Ensure the cables go through the cable clip ring. See
Figure 3-32.
3 Connect the RAID battery cable to the BBU interposer card on the LSI
9265-8i card, and connect the other end of the cable to the
corresponding connector on the RAID battery.
NOTE: When connecting the RAID battery cable, the BBU interposer card should
be installed on the LSI 9265-8i card. The BBU interposer card in the figure below
is just for you reference.
