Table 29. Thermal restriction matrix for air cooled configurations
Configuration
32 x 2.5-
inch SAS
16 x 2.5-
inch SAS +
8 x 2.5-
inch NVMe
24 x 2.5-
inch NVMe
16 x 2.5-
inch SAS
8 x 2.5-inch
SAS
Rear storage
No Rear
Drives
No Rear
Drives
No Rear
Drives
No Rear
Drives
No Rear
Drives
Processor TDP T-Case max center (°C) Ambient temperature
165 W 82
45°C
(113°F)
35°C
(95°F)
35°C
(95°F)
45°C
(113°F)
45°C (113°F)
185 W 81
45°C
(113°F)
35°C
(95°F)
35°C
(95°F)
45°C
(113°F)
45°C (113°F)
195 W 64
45°C
(113°F)
35°C
(95°F)
35°C
(95°F)
45°C
(113°F)
45°C (113°F)
250 W 83
40°C
(104°F)
35°C
(95°F)
35°C
(95°F)
40°C
(104°F)
40°C (104°F)
250 W 76
40°C
(104°F)
35°C
(95°F)
35°C
(95°F)
40°C
(104°F)
40°C (104°F)
270 W 72
40°C
(104°F)
35°C
(95°F)
35°C
(95°F)
40°C
(104°F)
40°C (104°F)
270 W 71
40°C
(104°F)
35°C
(95°F)
35°C
(95°F)
40°C
(104°F)
40°C (104°F)
330 W 76
35°C
(95°F)
35°C
(95°F)
35°C
(95°F)
35°C
(95°F)
35°C (95°F)
330 W 77
35°C
(95°F)
35°C
(95°F)
35°C
(95°F)
35°C
(95°F)
35°C (95°F)
350 W 79
35°C
(95°F)
35°C
(95°F)
35°C
(95°F)
35°C
(95°F)
35°C (95°F)
Memory Ambient temperature
256 GB RDIMM 35°C
(95°F)
35°C
(95°F)
35°C
(95°F)
35°C
(95°F)
35°C (95°F)
128 GB RDIMM 35°C
(95°F)
35°C
(95°F)
35°C
(95°F)
35°C
(95°F)
35°C (95°F)
64 GB RDIMM NA* NA* NA* NA* NA*
32 GB RDIMM NA* NA* NA* NA* NA*
16 GB RDIMM NA* NA* NA* NA* NA*
GPU Ambient temperature
Double width (300 W) NA NA
35°C
(95°F)
35°C
(95°F)
35°C (95°F)
NOTE: *Memory will have the same thermal restrictions of the processor used.
NOTE: Up to six standard (STD) dual fan modules must be installed in all of the configurations.
NOTE: GPU air shroud is required, when GPU is installed in the system.
NOTE: When riser slots four and nine are installed, the supported ambient temperature is 35°C (95°F).
NOTE: DIMM blanks must be installed in empty DIMM slots.
Technical specifications 35
