Figure 39. Installing the air shroud top cover
Next steps
1. Install the support bar.
2. Follow the procedure listed in After working inside your system.
Removing the air shroud
Prerequisites
CAUTION:
Never operate your system with the air shroud removed. The system may get overheated quickly,
resulting in shutdown of the system and loss of data.
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in Before working inside your system.
3. Remove the support bar.
4. Remove the air shroud top cover.
5. Remove the cooling fan cage assembly.
Steps
Press the latches on either sides of the air shroud, and lift the air shroud out of the system.
Installing and removing system components
79
