Figure 29. Installing the system cover
Next steps
1. Follow the procedure listed in After working inside your system.
Support bar
Removing the support bar
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in Before working inside your system.
CAUTION: The support bar must be removed before removing the air shroud.
Steps
1. Pull the plunger and rotate to lock the plunger on the support bar.
2. If full-length risers are installed, and then loosen the captive screws on the support bar that hold the risers.
3. Lift the support bar from the system.
Installing and removing system components
71
