Chassis dimensions
Figure 10. Chassis dimensions
Table 5.
Chassis dimension for the system
Drives Xa Xb Ya Yb Yc Za
(with
bezel)
Za
(without
bezel)
Zb Zc
8 x 3.5-inch
SAS/SATA
HDD/SSD
175.0 mm (6.89
inches)
N/A 369.5 mm
(14.55
inches)
382.5 mm
(15.06
inches)
N/A 19 mm
(0.75
inches)
N/A 560.5 mm
(22.07
inches)
562.12 mm
(22.13 inches)
System weight
Table 6.
PowerEdge T360 system weight
System configuration Maximum weight (with all drives/SSDs)
A server with fully populated drives 25.10 kg (55.34 lbs)
A server without drives and PSU installed 18.29 kg (40.32 lbs)
Processor specifications
Table 7.
PowerEdge T360 processor specifications
Supported processor Number of processors supported
Intel Xeon E-2400 series processor One
20 Technical specifications
