Dell PowerEdge T360 system overview
The PowerEdge T360 system is a single-socket 4.5U tower server that supports:
● One Intel Xeon E-2400 series processor with up to eight cores or Intel Pentium G7400/ G7400T processor with up to two
cores
●
Four UDIMM slots
● A Cabled AC or two redundant AC or DC power supply units
● Up to 8 x 3.5-inch SAS/SATA HDD/SSD drives
● Up to 4 x 3.5-inch SATA HDD/SSD drives
● Up to 8 x 2.5-inch SAS/SATA HDD/SSD drives with 3.5-inch to 2.5-inch adapter
NOTE: All instances of SAS and SATA drives are referred to as drives in this document, unless specified otherwise.
CAUTION: Do not install GPUs, network cards, or other PCIe devices on your system that are not validated
and tested by Dell. Damage caused by unauthorized and invalidated hardware installation will null and void the
system warranty.
Topics:
• Front view of the system
• Rear view of the system
• Inside the system
• Locating the Express Service Code and Service Tag
• System information labels
