Dell PowerEdge T360 - Thermal Restriction Matrix

Table 21. Continuous Operation Specifications for Rugged Environment(continued)
Temperature Allowable continuous operations
Operational altitude de-rating Maximum temperature is reduced by 1°C/125 m (33.8°F/410 Ft) above
900 m (2953 Ft).
Table 22. Common Environmental Specifications for ASHRAE A2, A3, A4, and Rugged
Allowable continuous operations
Maximum temperature gradient (applies to both
operation and non-operation).
20°C in an hour* (36°F in an hour) and 5°C in 15 minutes (41°F in 15
minutes), 5°C in an hour* (41°F in an hour) for tape
NOTE: * - Per ASHRAE thermal guidelines for tape hardware, these are
not instantaneous rates of temperature change.
Non-operational temperature limits -40 to 65°C (-40 to 149°F)
Non-operational humidity limits 5% to 95% RH with 27°C (80.6°F) maximum dew point
Maximum non-operational altitude 12,000 meters (39,370 ft)
Maximum operational altitude 3,048 meters (10,000 ft)
Table 23. Maximum vibration specifications
Maximum vibration Specifications
Operating 0.26 G
rms
at 5 Hz to 350 Hz (all operation orientations)
Storage 1.88 G
rms
at 10 Hz to 500 Hz for 15 minutes (all six sides tested)
Table 24. Maximum shock pulse specifications
Maximum shock pulse Specifications
Operating Six consecutively executed shock pulses in the positive and negative x, y,
and z axis of 6 G for up to 11 ms.
Storage Six consecutively executed shock pulses in the positive and negative x, y,
and z axis (one pulse on each side of the system) of 71 G for up to 2 ms.
Thermal restriction matrix
Table 25.
Label reference
Label Description
STD Standard
HPR High performance
HSK Heat sink
Table 26. Thermal restriction matrix
- TDP Number of Cores Configuration 1:
4x3.5-inch SATA
Configuration 2: 8x3.5-
inch SAS/SATA
HSK/FAN type HSK/FAN type
CPU TDP
95 W 8 HPR/STD HPR/STD
95 W 6 HPR/STD HPR/STD
80 W 8 STD/STD STD/STD
80 W 6 STD/STD STD/STD
70 W 4 STD/STD STD/STD
Technical specifications 27
