Dell PowerEdge T360 - Drives; Optical Drives; GPU Specifications; Ports and Connectors Specifications

Table 14. Storage controller cards (continued)
Supported storage controller cards
Internal Boot
● Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSDs drives
Software RAID
● S160
SAS Host Bus Adapters (HBA)
● HBA355e Adapter
Drives
The PowerEdge T360 system supports:
● Up to 4 x 3.5-inch SATA HDD/SSD drives
● Up to 8 x 3.5-inch SAS/SATA HDD/SSD drives
● Up to 8 x 2.5-inch SAS/SATA HDD/SSD drives with 3.5-inch to 2.5-inch adapter
Optical drives
The PowerEdge T360 system supports one Slim SATA DVD-ROM drive or DVD +/- RW drive.
NOTE: DVD devices support only data.
GPU specifications
The PowerEdge T360 system supports one 60 W single-width GPU.
NOTE: Systems that are configured with GPUs have higher fan acoustics.
NOTE: The T360 with GPU config is not recommended for an acoustic sensitive environment (table-top/floor standing
office environment, or general use space etc.).
Ports and connectors specifications
NIC port specifications
The PowerEdge T360 system supports up to two 10/100/1000 Mbps Network Interface Controller (NIC) ports embedded on
the LAN on Motherboard (LOM).
Table 15.
NIC port specification for the system
Feature Specifications
LOM on Planar 2 x 1 GbE
Network Card 1 GbE x 4, 10 GbE x 2, 10 GbE x 4
Serial connector specifications
The PowerEdge T360 system supports one serial port on the system board, which is Data Terminal Equipment (DTE), 16550-
compliant .
The serial connector is installed as default on the system board.
24
Technical specifications
