Table 32. System Information details(continued)
Option Description
System Manufacturer Specifies the name of the system manufacturer.
System Manufacturer Contact Information Specifies the contact information of the system manufacturer.
System CPLD Version Specifies the current version of the system Complex Programmable
Logic Device (CPLD) firmware.
UEFI Compliance Version Specifies the UEFI compliance level of the system firmware.
Memory Settings
To view the Memory Settings screen, power on the system, press F2, and click System Setup Main Menu > System BIOS
> Memory Settings.
Table 33. Memory Settings details
Option Description
System Memory Size Specifies the size of the system memory.
System Memory Type Specifies the type of memory installed in the system.
System Memory Speed Specifies the speed of the system memory.
Video Memory Specifies the size video memory.
System Memory Testing Specifies whether the system memory tests are run during system boot.
The two options available are Enabled and Disabled. This option is set to
Disabled by default.
Memory Operating Mode This field selects the memory operating mode. This feature is active
only if a valid memory configuration is detected. When Optimizer Mode
is enabled, the DRAM controllers operate independently in 64-bit mode
and provide optimized memory performance. When Dell Fault Resilient
Mode (FRM) is enabled, a percentage of the total installed memory is
configured to create a fault resilient zone starting from lowest system
memory address for use by select hypervisors for host virtualization
resilience. Specify the FRM percentage by using the Fault Resilient
Mode Memory Size[%] feature. When Dell NUMA Fault Resilient Mode
(FRM) is enabled, a percentage of the installed memory in every NUMA
node is configured to create a fault resilient zone for use by select
hypervisors for host virtualization resilience. Specify the FRM percentage
by using the Fault Resilient Mode Memory Size[%] feature.
Current State of Memory Operating Mode Specifies the current state of the memory operating mode.
Memory training When option is set to Fast and memory configuration is not changed,
the system uses previously saved memory training parameters to train
the memory subsystems and system boot time is also reduced. If memory
configuration is changed, the system automatically enables Retrain at
Next boot to force one-time full memory training steps, and then go back
to
Fast afterward.
When option is set to Retrain at Next boot, the system performs the
force one-time full memory training steps at next power on and boot time
is slowed on next boot.
When option is set to Enable, the system performs the force full
memory training steps on every power on and boot time is slowed on
every boot.
DIMM Population Provides information about the DIMM slots which has an installed DIMM.
34 Pre-operating system management applications
