Next steps
1. If you have unlatched the cable management arm, relatch it. For information about the cable management arm, see the
system’s rack documentation at https://www.dell.com/poweredgemanuals.
2. Connect the power cable to the PSU, and plug the cable into a power outlet.
CAUTION: When connecting the power cable to the PSU, secure the cable to the PSU with the strap.
NOTE: When installing, hot swapping, or hot adding a new PSU, wait for 15 seconds for the system to recognize the
PSU and determine its status. The PSU redundancy may not occur until discovery is complete. The PSU status indicator
turns green to indicate that the PSU is functioning properly.
NOTE: For certain premium configurations with high power consumption, system PSU might stay with 2+0 mode only, 1+1
redundant mode is not available.
NOTE: While replacing the hot swappable PSU, after next server boot; the new PSU automatically updates to the same
firmware and configuration of the replaced one. For more information about the Part replacement configuration, see the
Lifecycle Controller User's Guide at https://www.dell.com/idracmanuals
Power distribution board
This is a service technician replaceable part only.
Removing power interposer board (PIB)
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in the Before working inside your system .
3. Remove the PCI air shroud.
4. Remove both PSUs.
5. Disconnect all the cables that are connected to the system board, intrusion switch, Fan1, Fan 2 and Fan 3 from the power
interposer board (PIB).
NOTE:
The procedure to remove the power interposer board (PIB) is the same for Rear Accessed and Front Accessed
configurations.
Steps
1. Using a Phillips 2 screwdriver, remove the screws securing the power interposer board to the system.
NOTE: Observe the routing of the cables as you remove them from the system.
2. Lift the PIB away from the system.
142
Installing and removing system components
